PRODUCT DESCRIPTION
3D fabrics are a kind of exceptional reinforced materials among various fiber reinforcements. Its special frame offers excellent interlaminar shear strength, impact resistance, specific
strength & modulus and feasible toughness. 3D high performance fabrics are widely used in automotive, ships, wind energy, buildings, etc
FEATURES AND BENEFITS
Integrality of the Surface
Excellent mechanical property and stiffness
Good ablation resistance and anti-damage ability
| 3D Fabrics |
| Specification | Height (mm) | Area Weight (kg/m2) | Tensile Strength (Mpa) | Compressive Strength (Mpa) |
| DDE4 | 4.0 | 1.90 | 7.3 | 8.0 |
| DDE6 | 6.0 | 2.08 | 6.8 | 7.1 |
| DDE8 | 8.0 | 2.20 | 4.9 | 3.6 |
| DDE10 | 10.0 | 2.48 | 3.8 | 3.1 |
| DDE12 | 12.0 | 2.67 | 3.0 | 2.3 |
| DDE15 | 15.0 | 2.88 | 1.9 | 1.8 |
| DDE20 | 20.0 | 3.20 | 0.8 | 1.1 |
